Technical Specifications
MODEL | STYLE | MAX OPENING | HEIGHT | WIDTH | WEIGHT | WORKING PRESSURE | WORKING FLOW | CUT POWER | CUT POWER | CUT POWER | EXCAVATOR |
UNIT | mm | mm | mm | kg | bar | lpm | kn | kn | kn | ton | |
ZSTE-08 | rotating | 980 | 2530 | 1350 | 2100 | 260-300 | 100-120 | 550 | 800 | 1544 | 18-24 |
Application Fields:
Suitable for all kinds of concrete and steel structure demolition operations
Product Features:
1. Twin-pin system enables a larger opening and higher power, even at maximum opening;
2. Special tooth profile, studied to remain sharpen despite wear,maximizes penetration;
3. Interchangeable rebar cutting blades;
4. Speed-Valve improves productivity and protects the hydraulic system from pressure peaks;
5. Powerful cylinders develop enormous force which is increased and transferred to the jaws by a unique kinematics.
