Technical Specifications
MODEL | STYLE | MAX OPENING | HEIGHT | WIDTH | WEIGHT | WORKING PRESSURE | WORKING FLOW | CUT POWER | CUT POWER | CUT POWER | EXCAVATOR |
UNIT | mm | mm | mm | kg | bar | lpm | kn | kn | kn | ton | |
ZSTE-06 | rotating | 780 | 2074 | 1083 | 1240 | 220-260 | 80-100 | 349 | 408 | 994 | 12-15 |
Application Fields:
Suitable for all kinds of concrete and steel structure demolition operations
Product Features:
1. Twin-pin system enables a larger opening and higher power, even at maximum opening;
2. Special tooth profile, studied to remain sharpen despite wear,maximizes penetration;
3. Interchangeable rebar cutting blades;
4. Speed-Valve improves productivity and protects the hydraulic system from pressure peaks;
5. Powerful cylinders develop enormous force which is increased and transferred to the jaws by a unique kinematics.
